| Brand Name : | GUIHE |
| Model Number : | SYW-A |
| Certification : | CE , ExiaIIBT4 (Intrinsically safe) |
| Price : | 1-599 USD |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 500PIECE/ MONTH |
| Delivery Time : | WITHIN 3-5 DAYS |
Customized fuel management system with magnetostrictive probe and PC software / diesel stroage tank level monitor sensor
1. factory directly sell with best price for you
2. high quality and best service
3. wooden case and professional technology
4. Customized fuel management system,tank level probe, diesel storage tank station mornitor system PC software
fuel management system
Gas station level gauge consist of SYW-A magnetostrictive probe and touch control console (TCM-1,TCC-2,TCC-3).
SYW-A magnetostrictive probe installed in the tank,take the magnetostrictive technology,can accurately measure the inner tank oil level ,water level and multiple temperature;
Touch control console installed in the control room, it can automatically probe data acquisition and processing, real-time display can tank storage information, realize the tank leak detection, automatic unloading, record query, control multi-channel submersible pump,oil level alarm, data upload, and other functions.
SYW-A Magnetostrictive Probe
The probe consist of:
Fully enclosed magnetostrictive probe.
Electronic Pod using for data measuring and transforming.
Floater made according to the product.
Features:
Safety: ExiaIIBT4 (Intrinsically safe) issued by PCEC
Accuracy: level accuracy is ±0.3mm
Stability: strong anti-jamming ability
Efficiency: less than 1 second to test one tank.
Probe Performance
| Item | SYW-A |
| Purpose | To measure product level, water level and temperature |
| Titles of medium | Gasoline, diesel, kerosene, ethanol , water etc. |
| State of medium | Liquid |
| Explosion-proof grade | ExiaIIBT4 (Intrinsically safe) |
| Pressure range | -0.02Mpa~0.6Mpa |
| Certificate | PCEC Conformity Certificate of Explosion-proof / Permit of Manufacture Measuring Instruments |
| Temperature | -40℃~70℃ |
| Product Level Accuracy | ±0.3mm |
| Water Level Accuracy | ±0.3mm |
| Temperature Accuracy | ±0.2℃ |
| Height Resolution | 0.023mm |
| Repeatability | ±0.1mm |
| Environmental Temperature Effect | Error<0.2mm |
| Vibration Effect | Error<0.5mm |
| Lowest Product Inactive Zone | 2.5'' floater-180mm |
| Lowest Water Inactive Zone | 2.5'' floater-25mm |
| Measured Variable | Product level, interface level and temperature of 5 sensors and average temperature |
| Probe Length | 600~3500mm |
| Method of Communication | RS-485 |
| Probe Material | 1Cr18Ni9Ti |
| Power Supply | +24~26VDC |
| Protection Class of Probe Canister | IP67 |
| Max Communication Distance | 1200m |
diesel storage tank station mornitor system PC software
Qingdao Guihe Measurement & Control Technology Co.,Ltd is professional manufacuture about Gas station/Oil depot equipment . We have more than 13 Years production experience .
Our main produce as : gas station ATG/ automatic tank gauge , management system . double wall pipe leakage detector ,double wall tank leakage detector , hose type tanker truck ATG ,Magnetostrictive probe , touch contorl sonsole , Tank Calibration system/machine, high level alarm , gas alarm ,and others .
we are finding the DISTRIBUTOR in different country , welcome to contact us and talk about it !
|
|
